Properties
Product code: TS55-350-1125
Profile Height: 55 mm
Step length: 350 mm
Effective width: 1125 mm
Total width: 1153 mm
Maximum length: 8200 mm
Minimum length: 850 mm
Material thickness / weight per m2: 0.50 mm / 4.8 kg
Other technical information: Minimum slope 9° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: SR35-475C
Seam Height: 32 mm
Effective width: 475 mm
Total width: 505 mm
Maximum length: 10000 mm
Minimum length: 800 mm
Material thickness / weight per pcs: 0.50 mm / 5.2 kg
Other technical information: Minimum slope 6° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: SR35-475D
Seam Height: 32 mm
Effective width: 475 mm
Total width: 505 mm
Maximum length: 10000 mm
Minimum length: 800 mm
Material thickness / weight per m2: 0.50 mm / 5.2 kg
Other technical information: Minimum slope 6° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: TS52-330-1140
Profile Height: 52 mm
Step length: 330 mm
Effective width: 1140 mm
Total width: 1190 mm
Effective length: 660 mm
Material thickness / weight per m2: 0.50 mm / 5 kg
Material thickness / weight per pcs: 0.5 mm / 3.8 kg
Area of the roof / pcs: 0.75 m2
Other technical information: Minimum slope 14° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: TS39-350-1100
Profile Height: 39 mm
Step length: 350 mm
Effective width: 1100 mm
Total width: 1180 mm
Maximum length: 8000 mm
Minimum length: 850 mm
Material thickness / weight per m2: 0.5 mm / 4.7 kg
Area of the roof / pcs: 0.75 m2
Other technical information: Minimum slope 8° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: T20-29W-1095
Profile Height: 17 mm
Width of crown: 28.5 mm
Effective width: 1095 mm
Total width: 1129 mm
Maximum length: 12000 mm
Minimum length: 600 mm
Material thickness / weight per m2: 0.5 mm / 4.5 kg
Area of the roof / pcs: 0.75 m2
Other technical information: Minimum slope 6° (Suggestive value. Please check your local regulations and instructions)
Properties
Product code: SR32-475C
Profile Height: 32 mm
Effective width: 475 mm, 355 mm, 271 m
Total width: 512 mm, 392 mm, 308 mm
Maximum length: 10 000 mm
Minimum length: 200 mm*
Thickness / weight (kg/m2): 0.50 mm / 5.2 kg
Min. pitch: 8°
Sales unit: m2
Other technical informations: Posibility to order with additional acoustic andicondensation felt which reduces noise and prevent water condensation at the bottom of profiles
Properties
Product code: SR32-475D
Profile Height: 32 mm
Effective width: 475 mm
Total width: 512 mm
Maximum length: 10 000 mm
Minimum length: 200 mm*
Thickness / weight (kg/m2): 0.50 mm / 5.2 kg
Min. pitch: 8°
Sales unit: m2
Other technical informations: Posibility to order with additional acoustic andicondensation felt which reduces noise and prevent water condensation at the bottom of profiles
Properties
Product code: SR32-475M
Profile Height: 32 mm
Effective width: 475 mm, 355 mm, 271 m
Total width: 512 mm, 392 mm, 308 mm
Maximum length: 10 000 mm
Minimum length: 200 mm*
Thickness / weight (kg/m2): 0.50 mm / 5.2 kg
Min. pitch: 8°
Sales unit: m2
Other technical informations: Posibility to order with additional acoustic andicondensation felt which reduces noise and prevent water condensation at the bottom of profiles
Properties
Profile Height: 26 mm
Effective width: 1178 mm
Total width: 1200 mm
Effective length: 290 mm
Total length: 343 mm
Material thickness / weight per m2: 0.6 mm / 2.35 kg
Sales unit: m2
Area of the roof / pcs: 0.34 m2
Minimum Slope Distance: 25°
Other technical information: Pural BT Matt and GreenCoat Purex coating
- With a life expectancy of 50-60 years, metal roofing products last 2-3 times longer than other roofing options.
- Metal roofs are energy efficient and can actually help reduce heating and cooling bills by 20-25%.
- Metal roofing panels are fully recyclable at the end of their service life making them an environmentally friendly option.
- Metal roofs stand up to harsh weather events like hail and strong winds better than other roofing materials.
- Metal roofing panels are one of the lowest maintenance roofing products on the market.
- Kynar paint technologies allow metal roofing to retain it's like new curb appeal for decades.
Manufacturing of products meets all international standards
We will make an individual calculation of cost in just 15 minutes
We constantly improve production in order to achieve a carbon-neutral product
Our roofing materials look stylish and timeless
